i.Core MX6SX


Based on NXP™ i.MX 6SoloX processor, offers both the ARM Cortex-A9 and ARM Cortex-M4 cores, optimized for high performance energy efficient processing.

CPU NXP™ i.MX 6SoloX
INTEGRATED MCU Cortex™-M4
GRAPHICS 3D GPU
OPERATING TEMPERATURE -40° up to 85°

Specifications

CPU

  • Manufacturer NXP
  • Processor Family i.MX 6SoloX
  • Architecture ARM
  • Cores 1
  • Cores description 1x Cortex™-A9
  • Frequency Up to 1 GHz
  • Integrated MCU Cortex-M4

MEMORY

  • RAM Type DDR3L
  • RAM Frequency Up to 800MT/ss
  • RAM Size Up to 1GB
  • STORAGE on board 512 MB NAND Flash

GRAPHICS

  • GPU GPU3D
  • Features OpenGL ES 2.0
  • Other GPU2D (BitBlt) GPUVG—OpenVG 1.1; PiXel Processing Pipeline (PXP), Image re-sizing, rotation, overlay and CSC

VIDEO

  • LVDS Channels Single
  • Parallel RGB

VIDEO PROCESSING

  • Decoder Support Up to 1366x768
  • Encoder Support Up to 1366x768

USB

  • USB2 1
  • USB OTG 1

PCIe

  • Generation Gen2
  • Number 1
  • Aggregations 1-lane

NETWORKING

  • LAN PHY 2x 10/100 Megabit Ethernet

PERIPHERAL INTERFACES

  • UART Up to 5
  • I2C Up to 3
  • SPI Up to 4
  • CAN Up to 2
  • SDIO 2
  • GPIOs
  • Audio 1x I2S i/f
  • Other PWM, JTAG, Up to 8 ADC, Up to 4 Video ADC

OPERATING SYSTEM

  • Linux Yocto

GENERAL

  • Form Factor EDIMM
  • Dimensions 67.6 x 32 mm
  • Power Supply single 5V
  • Operational Temperature -40°C to +85°C
