i.MX6SoloX based EDIMM SOM


Based on NXP™ i.MX 6SoloX processor, offers both the ARM Cortex-A9 and ARM Cortex-M4 cores, optimized for high performance energy efficient processing.

Based on NXP™ i.MX 6SoloX processor. As the first device utilizing both the ARM Cortex-A9 and ARM Cortex-M4 cores, the i.MX 6SoloX applications processor offers a highly integrated multi-market solution. Optimized for high-performance energy-efficient processing in general embedded, automotive, industrial, and consumer applications. Provides for an application-rich system with real-time responsiveness. Enables secure, connected homes and vehicles within the Internet of Things (IoT).

CPU

  • NXP™ i.MX 6SoloX
  • Manifacturer: NXP
  • VPU

Cores

  • ARM
  • 1x Cortex™-A9, 1x Cortex™-M4
  • 1 cores

Memory

  • DDR3L 800
  • 512MB up to 1GB

Graphics

  • GPU3D—3D Graphics Processing Unit (OpenGL ES 2.0) GPU2D—2D Graphics Processing Unit (BitBlt) GPUVG—OpenVG 1.1

Video Interfaces

  • LVDS

Video Processing Unit Capabilities

  • Up to 1366x768

Mass Storage

  • 512MB Nand Flash
  • NAND

Networking

  • 2x LAN 100

USB

  • 1x OTG
  • 2x USB2

PCIe

  • 1 x PCIe interface
  • 1 lanes

Audio

  • 1 x I2S interface

Peripheral Interfaces

  • Up to 3 I2C Up to 4 SPI Up tp 6 PWM Up to 5 UART Up to 2 CAN Bus Up to 2 SDIO interfaces JTAG interface Up to 8 ADC Up to 4 Video ADC

Power Supply

  • single 5V

Operating System

  • Linux
  • Freeertos

Development System

  • Yocto

Operating Temperature

  • 0° up to 0°

Dimensions

  • 67.6 x 32.1 mm

Product availability

  • 2020

Hardware manual

  • Heatsink_assembly_i.Core_MX6SX_REV_A.pdf - 304.96K (please login to download)
  • i.CoreM6SX_HW_manual_1.1.0.pdf - 2.50M (please login to download)

Software manual

  • i.CoreM6S-DL-D-Q_SW_manual_Yocto_2.0.5.pdf - 6.18M (please login to download)

PCN

  • PCN_1503-2.pdf - 74.66K (please login to download)
  • PCN_1712-1.pdf - 90.52K (please login to download)
  • PCN_1807-1.pdf - 84.22K (please login to download)
  • PCN_1910-1.pdf - 129.61K (please login to download)

OS Images

  • This content is available for authorized users only. Please login.
