i.MX 6ULL based EDIMM-L 3V3 SOM





Based on NXP™ i.MX 6ULL processor. A power efficient and cost optimized applications processor family featuring an advanced implementation of a single ARM Cortex-A7 core, which operates at speeds up to 528 MHz. The GEA-L M6ULL module has been designed to have no video interface. The starter kit of the modules is equipped of the EDIMM evaluation board but the GEA-L M6ULL module does not allow the manage of any display

Operating Systems

Linux
CPU
CPU : NXP® i.MX 6ULL
Cores
Cores : Single-Core Cortex-A7@528MHz
Memory
Memory : Up to 512MB DDR3-800
Graphics
Graphics : -
Video Interfaces
Video Interfaces : -
Video Processing Unit Capabilities
Video Processing Unit Capabilities : -
Mass Storage
Mass Storage : Nand Flash
Networking
Networking : 1 x 10/100 Ethernet interface
USB
USB : 2 x USB
PCIe
PCIe : -
Audio
Audio : Up to 3 x I2S interface
Peripheral Interfaces
Peripheral Interfaces : Up to 4 I2C Up to 3 SPI Up tp 8 PWM Up to 8 UART Up to 1 CAN Bus Up to 2 SDIO interfaces JTAG interface
Power Supply
Power Supply : + 3.3V DC
Operative System
Operative System : Linux
Operating Temperature
Operating Temperature : Extended or industrial temperature available (see the manual for details)
Dimensions
Dimensions : 25 x 67.6 mm
Product availability (based on processor longevity program)
Product availability (based on processor longevity program) : Available at least until the Q4 2026
  • GEA-LMX6ULL_HW_Manual_1.0.6.pdf - 2.48M (please login to download)
  • PCN_1503-2.pdf - 74.66K (please login to download)
  • PCN_1808-1.pdf - 67.86K (please login to download)
This content is only available to authorized users after the login.
This content is only available to authorized users after the login.

Starterkit available for development
